medicaps unit-3 LAQ(11) (3)

Description

Que.11. A hexagonal prism, having a base with a 30 mm side and an 80 mm long axis, rests on one of its base edges in the H.P such that the axis is inclined at 30° to the HP and 45° to the VP. Draw its projections.
