MoTEX SLIT-220

Description

Slitting machine. CHARACTERISTICS STANDARD: Maximum belt width: 220mm; Slitting speed: 0… 150m / min; Unrolling belt diameter: max Φ500mm; Unwinding core: Φ70mm; Twisting band diameter: Φ100mm; Twisting core: Φ12 ... 45mm; AC motor with inverter control; Powder braking and clutch system; Electricity: 220 / 380V, 2 phases / 3 phases, 50 / 60Hz, 0.75kW; Size: 680mm (L) x 750mm (W) x 1350mm (H); CHARACTERISTICS OPTIONAL: Semi-turret system.
