Step 14 | Assembly instructions EEZYbotArm MK3

Description

**Assembly instructions**<br> * Attach *Stepper Gear* (19) to the Stepper Motor then insert it to *Cab* (03) with 2 M3 bolts, one is 6mm and the other is 10mm in length.<br> * Do the same for the other side of *Cab* (03).<br> * Attach the bottom part of *Link C* (08) to *Cab* (03) with M4 bolt, Washer and Self locking nuts where the head of the M4 bolt is facing the inside of *Cab* (03).<br> *Developer:* [eezyrobots.it](http://www.eezyrobots.it)
