Stop Motion
by trinityscsp in science-technology
1,614
Faces
1,664
Vertices
0
Textures
Free
Download
Description
This is a little different slider-crank mechanism. The rod has a slot that causes a backlash twice each turn. The result is a broken sine wave. Video at https://youtu.be/-FkzBNiYeus. Scheme at https://pin.it/1XzKabf.
