RGPV unit-3 LAQ (12)

Description

Que.12. A pentagonal prism, having a base 35 mm side and a 70 mm long axis has its axis inclined at 30° to VP. An edge of its base is in VP and inclined at 45° to the HP. Draw the projections.
