Gears-Cams-Sliders Hammer Mechanism

Description

Based on a picture found on Google Images. Two gears, same size, with different slot guides; The first moves the hammer from one position to another; The second moves the hammer down and up. Modeled with Solidworks 2015. Rendered with Simlab Composer 6 Mechanical Edition. Video at https://youtu.be/qXpPxKo2tBA.
