1to1 With Dwell Time III Mechanism

Description

The third of 3 mechanisms doing the same thing, but using different solutions. All of them have a 1:1 relation between input/output, but while input is continuous, output changes with time. This one uses a bevel gears planetary (differential type) combined with a woobling axle mechanism. The speeds add/subtract, resulting in an intermittent movement. Modeled with Solidworks 2015. Rendered with Simlab Composer 6 Mechanical Edition. Video at https://youtu.be/2g_yteUrj2o.
