medicaps unit-3 SAQ(3)

Description

Que.1. A regular pentagon plane of 30 mm sides is resting on H.P. on one of its sides with its surface 45° inclined to H.P & perpendicular to· V.P. Draw its projections using auxiliary plane method.
